AHB2APB Bridge IP

Truechip's AHB2APB Bridge IP provides chip designers and architects, with an efficient way to connect different Bus Protocol-based IPs with reduced latency, power, and area.

Key Benefits

• Available in native Verilog (RTL).
• Linting, Synthesis, CDC, RDC are cleaned up.
• Verified with an expert team using comprehensive and Regression Test Suites.
• Consistency of interface, installation, operation, and documentation across all our IPs.
• Easy GUI-based integration and configuration technique.
• 24X5 customer support.
• Unique and customizable licensing models.

Features

• Support Any type of protocol conversion between Tilelink, Amba AXI,AHB,APB, Like AXI to Tilelink, AXI to AHB, AHB to APB, TL-UH to TL-UL etc.
•  Interversion Transfer conversion like AHB5 to APB4.
• Port data width can be different.
• Apart from data width, other protocol-supported signals can also have different widths.
• Support all type of transfers.
• Breaking of transfer is possible.
• Early response also possible for write transfer.
• Support different phase-shifted frequencies for Master and Slaves.
• Clock enable disable mechanism.
• Support logical -physical address conversion.
• Both little & high endianness is supported.
• Arithmetic and logical transfer.
• Enable buffering.
• Interleaving support, Out of order transfer, Exclusives supports in AXI port.
• Secure Transfer.
• Support back-to-back transfers.
• reg slicing.

Deliverables

• Bridge IP (required Master & slave bridge ports, Like Tilelink, AXI, AHB, APB)
• IP generator & config tool
• Verilog Test Environment with Verilog Test cases
• IP analysis reports
  • Linting report
  • Synthesis report
• IP-XACT RDL generated address map
• Simulation script
• IP Block Guide
• Quick Start Guide
